日新发明的省开炼机的滤胶机,采用双挽喂料装置。广泛用于电缆行业、再生胶行业、内胎行业、胶管行业、塑胶跑道等橡胶制品厂商。可以使密炼机混炼好的胶料,无需老工艺经过开炼机出胶条喂入老式滤胶机，可团胶直接喂入双挽喂料机构。利用螺杆推挤、输送作用,把混炼胶或再生胶中的杂质清除掉,或挤出片状或造粒。主要由提升送料机、团胶喂料机构、螺杆、机筒、滤胶机头(出片机头、造粒机头)、自动切胶装置、温控系统和传动装置等组成。
产品特性:
1、团胶喂料过滤机,喂料效果好,过滤能力强,大大降低了工人的工作强度、降低了投资成本。与老机型相比较,减少了劳动强度、降低了投资成本。
6、多孔板用于支承过滤网并为排料口,是沿胶料流动方向扩张的锥形孔，节能、不烧胶。
The newly invented rubber filter for the provincial opening mill adopts a double feeding device. Ït is widely used in cable industry, reclaimed rubber industry, inner tube industry, rubber hose industry and plastic runway.Such as rubber products manufacturers. Mixed rubber can be made by internal mixer, without the need for the old process through the opening machine strip feeding into the old filter, can be directly fed into the double-pull glue feeder.Structure. By using screw pushing and conveying, impurities in mixing rubber or reclaimed rubber can be removed or extruded or granulated. Mainly by the lifting feeder, the rubber feeding mechanism,Screw, barrel, glue filter head (discharging head, granulating head), automatic glue cutting device, temperature control system and transmission device, etc.
Product characteristics:
1. The glue feeding filter has good feeding effect and strong filtering ability, which greatly reduces the working intensity of workers and the investment cost. Compared with the old model, it reduces labor intensity and reduces investment cost.
2. Hydraulic switching device, fast operation, no glue leakage, time saving and labor saving.
3. Electric control system uses frequency converter to improve resource utilization and energy saving.
4. Adopt special reducer for hard tooth extruder, with low noise and long service life.
5. Material barrel and screw are made of high quality alloy steel 38CrMoALA, Quenched and tempered and nitriding, wear resistant and durable.
产品特性:
1、团胶喂料过滤机,喂料效果好,过滤能力强,大大降低了工人的工作强度、降低了投资成本。与老机型相比较,减少了劳动强度、降低了投资成本。
2、液压换网装置,操作快速、不漏胶、省时、省力。
3、电控系统选用变频器,提高资源利用率,安全节能。
4、采用硬齿面挤出机专用减速箱，噪音低、使用寿命长。
5、料筒、螺杆选用优质合金钢38CrMoALA制造,经过调质氮化处理;耐磨耐用。6、多孔板用于支承过滤网并为排料口,是沿胶料流动方向扩张的锥形孔，节能、不烧胶。
The newly invented rubber filter for the provincial opening mill adopts a double feeding device. Ït is widely used in cable industry, reclaimed rubber industry, inner tube industry, rubber hose industry and plastic runway.Such as rubber products manufacturers. Mixed rubber can be made by internal mixer, without the need for the old process through the opening machine strip feeding into the old filter, can be directly fed into the double-pull glue feeder.Structure. By using screw pushing and conveying, impurities in mixing rubber or reclaimed rubber can be removed or extruded or granulated. Mainly by the lifting feeder, the rubber feeding mechanism,Screw, barrel, glue filter head (discharging head, granulating head), automatic glue cutting device, temperature control system and transmission device, etc.
Product characteristics:
1. The glue feeding filter has good feeding effect and strong filtering ability, which greatly reduces the working intensity of workers and the investment cost. Compared with the old model, it reduces labor intensity and reduces investment cost.
2. Hydraulic switching device, fast operation, no glue leakage, time saving and labor saving.
3. Electric control system uses frequency converter to improve resource utilization and energy saving.
4. Adopt special reducer for hard tooth extruder, with low noise and long service life.
5. Material barrel and screw are made of high quality alloy steel 38CrMoALA, Quenched and tempered and nitriding, wear resistant and durable.
б. The perforated plate is used to support the filter screen and is the discharge port. It is a conical hole expanding along the direction of the rubber material flow, which saves energy and does not burn glue.
